SNO 1.0MP WIFI IP Camera SNO-PT020-10

  • Model:SNO-PT020-10
  • Brand:SNO
  • Weight:0.6kg

SNO 1.0MP WIFI IP Camera

  1. Detailed Information
  2. Download

-HD 720P High definition image quality, resolution up to 1Megapixel, 1280*720.
-Magapixel Lens 3.6mm Megapixel lens.
-Pan and Tilt monitoring Pan 355degress;+Tilt 120degress, sliding screen manually enables remote control of the rotation of camera and real-time monitoring.

-Two Way Talk Build in microphone and high quality audio speaker, it can do two way talk online between camera and mobile phone.

-Infrared monitoring&Motion Detection When motion objects detected, it will trigger Email alert.

-10pcs IR Leds design, it can capture ultra clear night time image, max up to 8m IR range.Support Multi-Platform.

-Support Android/iOS mobile tablets and computers.

-TF card max up to 128G.Build in TF card slot, support max up to 128GB no need computer and HDDs and get video recorded.

-Dual AntennaDual antenna designed, WiFi connection is more stable and powerful.

-WiFi ConnectionWithout cabling work, via WiFi, it can be easily connected with your mobile for remote surveillance.

SystemOSEmbedded Linux OS
ProcessorHisilicon
Sensor1/4 720p Progressive CMOS sensor
VideoCompression FormatH.264
Video codingMain stream:1280*720@25fps; Sub stream:
640*352@25fps,320*176@25fps
Picture AdjustmentContrast, Brightness, Saturation, Flip and Mirror are adjustable.
Minimum illumination0.8Lux/F1.4 (colourful mode ),0.4Lux/F1.4 (B&W mode)
Bit RateCBR/VBR, bit rate range: 32-6144kbps
OSDSupport OSD
Lens3.6mm
Night VisionNight vision10pcs IR LED, 8m IR distance
IR controlIR turned on: night vision view enabled, infrared Ray, ICR auto detect.
IR turned off: night vision disabled, infrared ray off,
ICR stay in day view mode.
AudioCompression formatG.711A
InputBuilt in microphone
OutputBuilt in speaker
P/T FunctionP/TPan:355 degress;,Tilt:120 degress;
Preset Postionsupport up to 8 preset postions
NetworkNetwork interface10Base-T/100Base-TX Ethernet interface
Network ProtocolTCP/IP, HTTP, SMTP, FTP, DHCP, DDNS, NTP, UPnP, RTSP, RTMP, etc.
Online visitorSupport 5 online visitors simutaneoursly
IP addressDynamic IP and static IP address
WIFIWIFI 802.11 b/g/n
OnvifSupport Onvif protocol
AlarmMotion DetectionSupport 4 independent detection areas (sensitivity 1-100 )
Audible alarmAudible alarm(Sensitivity 1-100 )
Alarm linkageSending picture to Email;Uploading picture or video to FTP;Saving picture or video to TF card
OthersStorageSupport max to 128GB TF Card
Application environmentIndoor
Rated VoltageDC5±;0.3V
Temperature-10 to 50 ℃
Humidity10 -95%RH


Hot-Rotate-Remote-View-hd-720p-wifi (4).jpg
